Raspberry Pi Rackmount Kit | 12 Slot | 24x Connector | 19 inch | 3.00U | Rail System 300mm
>> Suitable for all Single Board Computers (SBC) with Raspberry Pi form factor
The illustrations shown, partly with cables shown schematically, are symbolic representations. They can contain extras that are subject to a surcharge (see configurator).
The illustrations shown, partly with cables shown schematically, are symbolic representations. They can contain extras that are subject to a surcharge (see configurator).
12 Pi an 24x Connector on 3.00U in the 19 inch server cabinet
With the “UM-SBC-211” you can neatly accommodate up to 12 Raspberry Pi´s and 24x Connectors or similar SBCs on 3.00U in the 19″ Rack.
Each Pi is screwed to the Rackmount Kit four times with M2.5 screws (included in the scope of supply).
Single board computers are not included.
Details
Configuration options of the “UM-SBC-211”
Like every Raspberry Pi Rackmount Kit from us, you can configure the “UM-SBC-211” according to your specific needs.
Rail System
This allows your devices to be conveniently operated by pulling out the rackmount kit. A telescopic rail on each side of the Raspberry Rack allows for easy access. The rail extension is 300 mm.
The Rail System is attached 4 times in the server cabinet and is suitable for cabinet depths of 400mm to 800mm (these are the minimum and maximum depth from the front posts to the rear ones).
We recommend it if you want to always have access to your memory card without dismantling the rackmount kit.
Keystone Inline Coupler
24x keystone connector slots are avaliable. Choose the keystone inline coupler type you need. Note that the “Push Button Connector” needs to be soldered.
Fan Holder for fan 40 or 60
The “UM-SBC-211” offers a mounting option for up to 6 fans (40 x 40 mm with a hole spacing of 32 x 32 mm / 60 x 60 mm with a hole spacing of 50 x 50 mm). This allows the devices to be additionally ventilated. The Fan Holder attaches to the rackmount kit with two screws behind the Pi.
Rack Panel
This allows the free space of the rack mount kit to be closed up to the next full rack unit.
UM-SBC-211
Delivery time: 4-5 days In Stock
Supported Models:
Raspberry Pi 2B
Raspberry Pi 3B
Raspberry Pi 3B+
Raspberry Pi 4B
Raspberry Pi 5
SBC with Raspberry Pi form factor | Details
Rack: 19 inch
Rack Unit: 3.00U
Material: Steel
Color: Black RAL 9005
Dimensions*: 482.6 x 132.2 x 310 mm
*) Dimensions = width/height/depth
Price starting from:
172,68 €
12 Pi an 24x Connector on 3.00U in the 19 inch server cabinet
With the “UM-SBC-211” you can neatly accommodate up to 12 Raspberry Pi´s and 24x Connectors or similar SBCs on 3.00U in the 19″ Rack.
Each Pi is screwed to the Rackmount Kit four times with M2.5 screws (included in the scope of supply).
Single board computers are not included.
Details
Configuration options of the “UM-SBC-211”
Like every Raspberry Pi Rackmount Kit from us, you can configure the “UM-SBC-211” according to your specific needs.
Rail System
This allows your devices to be conveniently operated by pulling out the rackmount kit. A telescopic rail on each side of the Raspberry Rack allows for easy access. The rail extension is 300 mm.
The Rail System is attached 4 times in the server cabinet and is suitable for cabinet depths of 400mm to 800mm (these are the minimum and maximum depth from the front posts to the rear ones).
We recommend it if you want to always have access to your memory card without dismantling the rackmount kit.
Keystone Inline Coupler
24x keystone connector slots are avaliable. Choose the keystone inline coupler type you need. Note that the “Push Button Connector” needs to be soldered.
Fan Holder for fan 40 or 60
The “UM-SBC-211” offers a mounting option for up to 6 fans (40 x 40 mm with a hole spacing of 32 x 32 mm / 60 x 60 mm with a hole spacing of 50 x 50 mm). This allows the devices to be additionally ventilated. The Fan Holder attaches to the rackmount kit with two screws behind the Pi.
Rack Panel
This allows the free space of the rack mount kit to be closed up to the next full rack unit.
Configurator
Configure the Rack Mount Kit according to your requirements here.
Available build space for Raspberry Pi add-on boards
If you are considering adding additional cards such as PoE HAT or PCIe expansion cards to the rack, see below for available space.
Insert D
Suitable for Raspberry Pi with Poe-HAT.
Insert E | Insert F
Suitable for Raspberry Pi with Poe-HAT.
Single Board Computer with identical form factor for Raspberry Pi
As mentioned above, you can mount single board computers with the same form factor as the Pi 5 in the Raspberry Pi Rackmount Kit. Pay attention to the basic dimensions of the Pi and the drilling pattern/diameter.
If they match, your single-board computers are compatible with our rack and can therefore be used without any problems. Single board computers tested by us for compatibility are: ASUS Tinker Board | ODROID-C1+
1 review for UM-SBC-211
Only logged in customers who have purchased this product may leave a review.
Nicholas Henson –
While looking around the internet for a raspberry pi rack mount system I came across Racknex. There aren’t many options available. Most are simple single bent steel brackets with a few cutouts and just two posts to hold them in. Others are steel boxes with no frills and lots of sourcing of accessories. I was pleased to see that there was a professionally constructed mount with more options than you could shake a stick at for not much more than the cheap racks. Upon receiving the rack, I was also pleasantly surprised by how well this was packed with shipping foam. It would be hard for this to get damaged in transit. I chose options for the LCD touchscreen and mounting four other Pi’s with hats. Everything is well built. If you need to replace or move the ports, they are standard keystones. You can use your own if need something special special or just want to save a bit of money. I highly recommend their products and will be ordering a few other racks for some small computers.
