Features of our ASUS Rack Mounts
Assembly of my ASUS Rackmount Kit
The ASUS is attached to the rackmount kit using Velcro straps. So no screws are necessary and you don’t have to unscrew your device. The rackmount kit comes fully assembled and ready for use.
All rackmount kits are designed to support good air circulation. Using our self-developed spacers in combination with the Velcro straps, the ASUS is mounted in such a way that the existing ventilation openings are not affected. This allows us to achieve a time-saving and device-friendly assembly solution.
Air System
Cutouts for air circulation are provided at the points where the ASUS and its power supply unit are mounted and bring sufficient cooling in your system.
Rail System
With the rail system you can easily extend the ASUS by 200 mm. The fully extendable telescopic rails allows for easy access and makes commissioning and maintenance work on the device much easier.
Strap System
The ASUS is attached to our rackmount kits in a screwless, secure and non-slip manner using a special strap system, without screws or other aids affecting the device. To avoid damage to the housing, the straps are fixed with high-quality Velcro. This also prevents a possible loss of warranty.
Socket Management
Using a high-quality Keystone inline coupler and cable combination, we bring the ASUS connectors from the back to the front of the rack mounting kit. The keystones are installed flush and make further cabling in the rack much easier. Each socket is labeled with a front foil.
Scope of supply
All ASUS rack mount kits have the following as standard included in the scope of supply.
- – Rack Mount Screw Set
- – Cable Tie 100mm
- – Cable Tie 300mm
- – Velcro Strap with Spacer
- – Product Data Sheet
- – Assembly Instructions
ASUS Rackmount Kit accessories
In order to tailor your ASUS rackmount kit set to your individual needs, a configurator with a large selection and many combination options is available on each product page.
Our ASUS Rack Mount Kits
What is the right ASUS Rack Mount Kit for me?
We currently offer ASUS Rackmount Kits, all supporting:
- – ASUS NUC 11 Essential
- – ASUS NUC 14 Essential
- – ASUS NUC 12 Pro
- – ASUS NUC 13 Pro
- – ASUS NUC 14 Pro
- – ASUS NUC 15 Pro
- – ASUS NUC 14 Pro+
- – ASUS NUC 15 Pro+
1.00U ASUS NUC Rack Mount for 19″ racks
The following ASUS NUC rackmount kits are specifically designed and developed for installation in a 19″ rack on 1.00U.
This ASUS NUC Rack Mount Kit is designed to mount one ASUS NUC 11 Essential, ASUS NUC 14 Essential or Intel NUC 11 Essential Kit Mini PC with power supply and 7 ports in 19 inch racks on 1.00U. Select the connector configuration that matches your ASUS NUC product model. Optionally, you can configure a “Rail System” to extend the rack mount kit by 200mm.
This ASUS NUC Rack Mount Kit is designed to mount one ASUS NUC 12 Pro Slim / ASUS NUC 13 Pro Slim / ASUS NUC 14 Pro Slim / ASUS NUC 15 Pro Slim Mini PC with power supply and 7 ports in 19 inch racks on 1.00U. To cover every product type we have made all connections configurable. Select the connector configuration that matches your ASUS NUC product model. Optionally, you can configure a “Rail System” to extend the rack mount kit by 200mm.
This ASUS NUC Rack Mount Kit is specially designed for mounting two ASUS NUC 12 Pro Slim / ASUS NUC 13 Pro Slim / ASUS NUC 14 Pro Slim / ASUS NUC 15 Pro Slim Mini PC with power supplies and 6 ports in 19 inch racks on 1.00U. To cover every product type we have made all connections configurable. Select the connector configuration that matches your ASUS NUC product model. The ASUS NUC PCs can be mounted in either directions. Ports face forward or power switch faces front. Optionally, you can configure a “Rail System” to extend the rack mount kit by 200 mm, or temporarily/permanently cover a free slot with our “Slot Cover”.
This ASUS NUC Rack Mount Kit is specially designed for mounting three ASUS NUC 12 Pro Slim / ASUS NUC 13 Pro Slim / ASUS NUC 14 Pro Slim / ASUS NUC 15 Pro Slim Mini PC with power supplies on 1.00U in a 19-inch rack. The ASUS NUC PCs can be mounted in either directions. Ports face forward or power switch faces front. Optionally, you can configure a “Rail System” to extend the rack mount kit by 200 mm, or temporarily/permanently cover a free slot with our “Slot Cover”.
1.00U ASUS NUC Rack Mount for 10″ racks
The following ASUS NUC rackmount kits are specifically designed and developed for installation in a 10″ rack on 1.00U.
This ASUS NUC Rack Mount Kit is specially designed for mounting one ASUS NUC 12 Pro Slim / ASUS NUC 13 Pro Slim / ASUS NUC 14 Pro Slim Mini PC with power supplies and 3 ports in 10 inch racks on 1.00U. To cover every product type we have made all connections configurable. Select the connector configuration that matches your ASUS NUC product model. The ASUS NUC PCs can be mounted in either directions. Ports face forward or power switch faces front. Optionally, you can configure a “Rail System” to extend the rack mount kit by 200mm.
1.33U ASUS NUC Rack Mount for 19″ racks
The following ASUS NUC rackmount kits are specifically designed and developed for installation in a 19″ rack on 1.33U.
Different heights? No problem
The cases of the ASUS NUC models from the Pro series have two form factors, Slim and Tall. They differ greatly in height. From 36 mm – 54 mm.
If you want to combine different NUC Pro models with different form factors, our “ASUS NUC Slot Adapter” will help you. Use the Slot Adapter to compensate for the height differences of the form factors.
This ASUS NUC Rack Mount Kit is specially designed for mounting two ASUS NUC 14 Pro+ 0r ASUS NUC 15 Pro+ with power supplies and 8 ports in 19 inch racks on 1.33U. We have made all connections configurable. Select the connector configuration that fits you the best. The ASUS NUC PCs can be mounted in either directions. Ports face forward or power switch faces front. Optionally, you can configure a “Rail System” to extend the rack mount kit by 200 mm, or temporarily/permanently cover a free slot with our “Slot Cover”.
This ASUS NUC Rack Mount Kit is specially designed for mounting two ASUS NUC 12 Pro Slim & Tall / ASUS NUC 13 Pro Slim & Tall / ASUS NUC 14 Pro Slim & Tall / ASUS NUC 15 Pro Slim & Tall Mini PC with power supplies and 12 ports in 19 inch racks on 1.33U. To cover every product type we have made all connections configurable. Select the connector configuration that matches your ASUS NUC product model. The ASUS NUC PCs can be mounted in either directions. Ports face forward or power switch faces front. Optionally, you can configure a “Rail System” to extend the rack mount kit by 200 mm, or temporarily/permanently cover a free slot with our “Slot Cover”.
This ASUS NUC Rack Mount Kit is specially designed for mounting three ASUS NUC 12 Pro Slim & Tall / ASUS NUC 13 Pro Slim & Tall / ASUS NUC 14 Pro Slim & Tall / ASUS NUC 15 Pro Slim & Tall Mini PC with power supplies on 1.33U in a 19-inch rack. The ASUS NUC PCs can be mounted in either directions. Ports face forward or power switch faces front. Optionally, you can configure a “Rail System” to extend the rack mount kit by 200 mm, or temporarily/permanently cover a free slot with our “Slot Cover”.
1.66U ASUS NUC Rack Mount for 10″ racks
The following ASUS NUC rackmount kits are specifically designed and developed for installation in a 10″ rack on 1.66U.
Different heights? No problem
The cases of the ASUS NUC models from the Pro series have two form factors, Slim and Tall. They differ greatly in height. From 36 mm – 54 mm.
If you want to combine different NUC Pro models with different form factors, our “ASUS NUC Slot Adapter” will help you. Use the Slot Adapter to compensate for the height differences of the form factors.
This ASUS NUC Rack Mount Kit is specially designed for mounting one ASUS NUC 12 Pro Slim & Tall / ASUS NUC 13 Pro Slim & Tall / ASUS NUC 14 Pro Slim & Tall / ASUS NUC 15 Pro Slim & Tall Mini PC with 6 ports in 10 inch racks on 1.66U. To cover every product type we have made all connections configurable. Select the connector configuration that matches your ASUS NUC product model.
