WatchGuard Firebox T20 / Firebox T25 / Firebox 40 / Firebox 45 Rackmount Kit | 19 inch | 1.33U | Rail System 200mm

WatchGuard T20 rackmount
WatchGuard T20 rackmount kit
WatchGuard T40 rackmount
WatchGuard T40 rack mount kit
WatchGuard T40 19 inch rackmount
WatchGuard T40 rackmount kit
WatchGuard T20 rack mount kit
WatchGuard T20 rackmount - NM-WAG-201
WatchGuard T20 rackmount kit - NM-WAG-201
WatchGuard T40 rackmount - NM-WAG-201
WatchGuard T40 rack mount kit - NM-WAG-201
WatchGuard T40 19 inch rackmount - NM-WAG-201
WatchGuard T40 rackmount kit - NM-WAG-201
WatchGuard T20 rack mount kit - NM-WAG-201
previous arrow
next arrow
WatchGuard T20 rackmount - NM-WAG-201
WatchGuard T20 rackmount kit - NM-WAG-201
WatchGuard T40 rackmount - NM-WAG-201
WatchGuard T40 rack mount kit - NM-WAG-201
WatchGuard T40 19 inch rackmount - NM-WAG-201
WatchGuard T40 rackmount kit - NM-WAG-201
WatchGuard T20 rack mount kit - NM-WAG-201
previous arrow
next arrow

The illustrations shown, partly with cables shown schematically, are symbolic representations. They can contain extras that are subject to a surcharge (see configurator).

The illustrations shown, partly with cables shown schematically, are symbolic representations. They can contain extras that are subject to a surcharge (see configurator).

Mount WatchGuard Firebox T20, T25, T40 or T45 with a Rack Mount Kit in the 19 inch rack

Install your WatchGuard Firebox T20, T25, T40 or T45 conveniently and easily with our Rack Mount Kit „NM-WAG-201“ in the 19 inch rack. With our „Strap-System“, we enable easy, tool-free assembly and in combination with our „Air-System“, your device always keeps a cool head. All of our rackmount kits are individually configurable. Choose the configuration that suits you below.

Details

Details

This WatchGuard rackmount kit was specially developed for installation in a 19 inch rack.

  • All assembly and plug-in connections have been matched.
  • We use keystone inline couplers for our connectors.
  • You can choose between a shielded and unshielded version.
  • The WatchGuard Firewall is not in the scope of supply.

Strap-System

The devices are attached to the rackmount kit using Velcro straps. So no screws are needed and you don’t have to unscrew your device. The rackmount kit comes fully assembled and ready to use.

Air-System

All rackmount kits are designed to support good airflow. With our self-developed spacers in combination with the Velcro straps, the device is mounted in such a way that the existing ventilation openings are not impaired. This enables us to achieve a time-saving, device-friendly assembly solution.

NM-WAG-201

Delivery time: 7-8 weeks

Supported Models:
WatchGuard Firebox T20
WatchGuard Firebox T25
WatchGuard Firebox T40
WatchGuard Firebox T45

Rack: 19 inch
Rack Unit: 1.33U
Material: Steel
Color: Black RAL 9005
Dimensions*: 482.6 x 58.2 x 210 mm

*) Dimensions = width/height/depth

Price starting from:

148,20

Mount WatchGuard Firebox T20, T25, T40 or T45 with a Rack Mount Kit in the 19 inch rack

Install your WatchGuard Firebox T20, T25, T40 or T45 conveniently and easily with our Rack Mount Kit „NM-WAG-201“ in the 19 inch rack. With our „Strap-System“, we enable easy, tool-free assembly and in combination with our „Air-System“, your device always keeps a cool head. All of our rackmount kits are individually configurable. Choose the configuration that suits you below.

Details

Details

This WatchGuard rackmount kit was specially developed for installation in a 19 inch rack.

  • All assembly and plug-in connections have been matched.
  • We use keystone inline couplers for our connectors.
  • You can choose between a shielded and unshielded version.
  • The WatchGuard Firewall is not in the scope of supply.

Strap-System

The devices are attached to the rackmount kit using Velcro straps. So no screws are needed and you don’t have to unscrew your device. The rackmount kit comes fully assembled and ready to use.

Air-System

All rackmount kits are designed to support good airflow. With our self-developed spacers in combination with the Velcro straps, the device is mounted in such a way that the existing ventilation openings are not impaired. This enables us to achieve a time-saving, device-friendly assembly solution.

Configurator

Configure the Rack Mount Kit according to your requirements here.

148,20

Delivery time: 7-8 weeks

  • This allows your devices to be conveniently operated by pulling out the rack mount kit.

  • This allows the rear network connections of your device to be operated on the front of the rack mount kit.

    *RJ45 Network Connector
    *RJ45 Network Cable
    *RJ45 Network Cable
    *RJ45 Network Cable
  • This allows the rear USB 3.0 connections of your device to be operated on the front of the rack mount kit.

    *USB 3.0 Connector
    *USB 3.0 Cable
    *USB 3.0 Cable
  • This allows the free space of the rack mount kit to be closed up to the next full rack unit.
